Each PDU contains a function code and associated data. Within each ADU, there is a protocol data unit (PDU) that is the core of the Modbus protocol. From the point of view of the application using Modbus, data should simply be exposed as if the ADU did not exist.
RTU and ASCII are older serial ADU formats with the primary difference between the two being that RTU uses a compact binary representation while ASCII sends all requests as streams of ASCII characters.įor most applications, the preferred ADU depends on the desired physical network (Ethernet, serial, or something else), the number of devices on the network, and the ADUs supported by the master and slave devices on the network. TCP is a modern format that allows for efficient handling of Modbus requests and responses in software, as well as more efficient networking through the use of dedicated connections and identifiers for each request. There are three ADUs: ASCII, remote terminal unit (RTU), and TCP/IP.
The first layer is the application data unit (ADU), which is what most people consider to be the “type” of Modbus used. In Modbus, this request is a layered set of data. The Master-Slave, Request-Response Relationship of Modbus Devices Even on modern TCP/IP networks, it gives the master a high degree of control over slave behavior, which is helpful in some designs.įigure 1.
LABVIEW MODBUS SERIAL EXAMPLE ARDUINO FULL
This architecture gives the master full control over the flow of information, which has benefits on older multidrop serial networks. The Modbus protocol follows a master and slave architecture where a master transmits a request to a slave and waits for the response.
